SN Ref. Part No. Mindrill Part No. Descriptions Qty.
1 – 5122 103 002 Back Head 1
2 F814725 5122 102 003 Throttle Lever 1
3 R133433 5122 102 004 Thrttle Lever Pin 2
4 R075031 5122 103 001 Oil Plug 1
5 F816345 5122 102 002 Rubber Grip 2
6 C036901 5122 103 007 Plug Oil Regulater 1
7 R006131 5122 103 009 Back Head Bolt Nut 4
8 P006239 5122 103 010 Lock Washer 4
9 R047961 5122 103 005 Valve Case Spring 1
10 R068064|P009876 5121 116 034 Pipe Plug 1
11 R047958 5122 103 004 Valve Case 1
12 R049854 5122 103 013 O-ring 2
13 R047959 5122 103 012 Valve 1
14 R047960 5122 103 011 Valve Case Lid 1
15-17 R092894 5122 102 015 80 Throttle Valve Com.(SN 15,16,17) 1
15 – 5122 102 015 Throttle Valve 1
16 R098368 5122 102 016 Throttle Valve Seal 1
17 R098369 5122 102 017 Throttle Valve Retaining Ring 1
18 R005717 5122 102 018 Spring Throttle Valve 1
19 R047965 5122 103 017 Cylinder Seal 1
20 R047962 5122 103 021 Back Head Bolt 4
21 C8549445 5122 103 025 Cylinder 1
22 R085269 5122 103 020 Air Inlet Swivel 1
23 R110317 5122 103 022 O-ring 1
24 P103521 5122 103 023 O-ring 1
25 R000530 5122 103 019 Air Inlet Swivel Nut 1
26 R047967 5122 103 024 Piston 1
27 R047966 5122 103 027 Anvil Block Bushing 1
28 R085260 5122 103 028 Anvil Block 1
29 R047969 5122 103 029 Latch Type Front Head (1 1/4″ Hex X 6 1/4″ Long) 1
29.1 R047968 5122 103 029 50 Latch Type Front Head (1 1/8″ Hex X 6 1/4″ Long) (Optional) 1
30 R047970 5122 103 026 Front Head Bolt 2
31 R047971 5122 103 030 Front Head Bolt Spring 2
32 R090584 5122 103 032 Front Head Bolt Lock Nut 2
33 R005721 5122 103 033 Front Head Bolt Nut 2
34 P008999 5122 103 037 Nylock Nut 1
35 R076562 5122 103 038 Latch Retainer Bolt Bushing 2
36 R086982 5122 102 035 Retainer Latch Plunger Spring 1
37 R076853 5122 103 039 Latch Retainer Bolt 1
38 R092497 5122 102 036 Retainer Latch Plunger 1
39 R055818 5122 103 035 Retainer Latch Bushing 1
40 R092493 5122 102 038 Retainer Latch 1
41 – 5122 103 042 Data Plate 1
42 – 5122 103 041 50 Muffler (Optional) 1
