SL. Part No. Description Qty.
1 5121 116 001 CHUCK -7/8″ Hex X 4 1/4″ 1
1a 5121 116 001 50 CHUCK -7/8″ Hex X 3 1/4″ 1
1b 5121 116 001 51 CHUCK -1″ Hex X 3 1/4″ 1
2 5121 116 002 RETAINER TRUNION 2
3 5221 116 003 RETAINER LATCH SHOE 1
4 5221 116 004 RETAINER BUFFER 1
5 5121 116 005 RETAINER -7/8″ 1
5a 5121 116 005 50 RETAINER -1″ 1
6 5221 116 006 “RETAINER TRUNION NUT (Nyloc Nut)” 2
7 5121 116 007 FRONT HEAD 7/8″Hex X4 1/4″ &1″ Hex X 4 1/4 1
7a 5121 116 007 50 FRONT HEAD 7/8″Hex X 3 1/4″ 1
8 5121 116 008 CHUCK SLEEVE-7/8″Hex X4 1/4″ &1″ Hex X 4 1/4 1
8a 5121 116 008 50 CHUCK SLEEVE-7/8″Hex X3 1/4″ 1
8b 5121 116 008 51 CHUCK SLEEVE-7/8″Hex X3 1/4″ (Modified threaded type) 1
5121 116 008 52 CHUCK SLEEVE-7/8″HEX X3 1/4″ (INBUILT CHUCK NUT TYPE) 1
9 5121 116 009 CHUCK ROTATION NUT 1
9a 5121 116 009 50 CHUCK ROTATION NUT (Threaded) 1
10 5121 116 010 CYLINDER BUSHING 1
11 5121 116 011 PISTON 1
12 5121 116 012 RIFLE BAR NUT(Steel) 1
12.1 5121 116 012 50 RIFLE BAR NUT(Bronze) 1
(13-14) 5221 116 013 80 OIL PLUG,Complete 1
13 5121 116 013 GASKET FOR OIL PLUG 1
14 5121 116 014 OIL PLUG 1
(15-16) 5121 116 015 80 CYLINDER,Complete 1
15 5121 116 015 CYLINDER 1
16 5121 116 016 BLOWER VALVE BUSH 1
17 5121 116 017 BLOWER VALVE 1
18 5221 116 018 BLOWER VALVE WASHER 1
19 5221 116 019 BLOWER VALVE SPRING 1
20 5221 116 020 BLOWER VALVE SPRING WASHER 1
21 5221 116 021 BLOWER VALVE SPRING PIN 1
22 5121 116 022 SIDE ROD NUT 2
23 5121 116 023 VALVE CASE 1
24 5221 116 024 STEM OIL REGULATION 1
25 5221 116 025 OIL REGULATION PLUG 1
26 5121 116 026 VALVE 1
27 5121 116 027 VALVE GUIDE BUSHING 1
28 5121 116 028 RATCHET RING 1
29 5221 116 029 VALVE CASE DOWEL 1
30 5121 116 030 RIFLE BAR 1
31 5221 116 031 PAWL SPRING 4
32 5121 116 032 PAWL 4
33 5121 116 033 BACK HEAD 1
34 5221 116 034 PLUG FOR THROTTLE VALVE PLUNGER SPRING 2
(35a-35b) 5121 116 035 80 THROTTLE VALVE HANDLE COMPLETE 1
35a 5121 116 035 THROTTLE VALVE HANDLE 1
35b 5221 116 035 20 THROTTLE VALVE HANDLE PIN 1
36 5221 116 036 LOCK WASHER 1
37 5121 116 037 THROTTLE VALVE HANDLE NUT 1
38 5221 116 038 BUSHING BLOW TUBE 1
41 5121 116 041 “BLOWER PORT PLUG (Dry Models Only)” 1
42 5121 116 042 THROTTLE VALVE PLUNGER 1
43 5221 116 043 THROTTLE VALVE PLUNGER SPRING 1
44 5221 116 044 WATER TUBE PLUG GASKET 1
46 5121 116 046 THROTTLE VALVE 1
47 5221 116 047 O’ RING FOR SWIVEL NUT 1
48 5221 116 048 O’ RING FOR SWIVEL 1
49 5121 116 049 AIR INLET SWIVEL 1
50 5121 116 050 AIR INLET SWIVEL NUT 1
51 5221 116 051 STRAINER 1
52 5221 116 052 WATER TUBE RUBBER 1
53 5121 116 053 WATER TUBE WASHER 1
54 5121 116 054 80 “BLOWER TUBE COMPL(Dry Only).” 1
55 5121 116 055 AIR TUBE PLUG 1
56 5121 116 056 HANDLE BOLT 1
57 5121 116 057 HANDLE BRACKET 1
58 5221 116 058 LINER FOR HANDLE 2
5221 116 059 80 RUBBER HANDLE COMPLETE 1
59 5221 116 059 RUBBER HANDLE 2
60 5221 116 060 WASHER FOR HANDLE BOLT 1
61 5221 116 061 NUT FOR HANDLE BOLT 1
62 5121 116 062 SIDE ROD 2
63 5121 116 063 COUPLING(3/4” NTP) 1
64 5121 116 064 NIPPLE (3/4” NTP X 1 1/2” UNC) 1
65 5121 116 065 HOSE END 1
66 5221 116 066 WASHER 1
67 5121 116 067 UNION NUT 1
(68-71) 5121 118 068 80 FOOT REST COMPLETE 1
68 5121 118 068 BRACKET 2
68A 5121 118 068 20 CLAMPING PIECE 2
68B 5121 118 068 21 TOP PLATE 1
68C 5121 118 068 22 SIDE PLATE 1
68D 5121 118 068 23 REST BAR 1
69 5221 118 069 RUBBER GRIP 2
70 5221 118 070 HEX. BOLT 2
71 5221 118 071 NUT 4
90 5221 116 090 NAME PLATE 1
