Weight : | 32.4 kg |
Length without Leg : | 688 mm |
Air consumption @6 Bar : | 86.36 l/s |
Drill Steel Chuck Hex : | 22×108 mm |
Piston diameter : | 76 mm |
Stroke length : | 64 mm |
Air Hose Connection : | 25 mm |
Water Connection : | 13 mm |
Impact rate : | 2256 BPM |
Compatible Pusher Legs : | TUL 2B, FL7 |
Part No. | Chuck Size | Air Connection |
---|---|---|
5111 139 000 | 22 x 108 mm(7/8 x 4¼ in) | 25 mm(1 in) |
