The MH501L Pneumatic Rock Drill is a winner when it comes to ease of use in tight spaces due to its low-weight and robust rifle bar rotation mechanism. This lightweight drill has been used for years for small jobs and is most suitable for mines with confined operator spaces. The drill allows miners to achieve depths of up to 1.5 meters (5 feet) with minimal air consumption. The T-grip handles along with its low-weight make the experience much more comfortable from the operator point of view. The air flushing system built into the drill rod prevents drill jamming by removing drill chips.
Weight : | 17.8 kg |
Length : | 510 mm |
Bore Diameter : | 28 mm x 34 mm |
Stroke Length : | 60 mm |
Air Consumption : | 39 l/s |
Penetration Rate : | 275 mm/min |
Piston Diameter : | 55 mm |
Chuck Size : | 22 mm x 108 mm |
Impact Rate : | 2100 BPM |
Revolutions : | 190 RPM |
Weight : | 40 lb |
Length : | 20 in |
Bore Diameter : | 1 1/8 in x 1 3/8 in |
Stroke Length : | 2 3/8 in |
Air Consumption : | 83 cfm |
Penetration Rate : | 10 3/4 in/min |
Piston Diameter : | 2 1/8 in |
Chuck Size : | 7/8 in x 4 1/4 in |
Impact Rate : | 2100 BPM |
Revolutions : | 190 RPM |
Part No. | Chuck Size |
---|---|
5111 113 000 | 22 x 108 mm (7/8 in x 4¼ in) |
Weight : | 9.8 kg |
Length : | 565 mm |
Bore Diameter : | 17 mm x 29 mm |
Stroke Length : | 41 mm |
Air Consumption : | 24 l/s |
Penetration Rate : | 230 mm/min |
Weight : | 11.1 kg |
Chuck Size : | 22 x 108 mm |
Length : | 505 mm |
Air Consumption : | 24 l/s |
Impact Rate : | 2580 BPM |
Revolutions : | 220 RPM |
Weight : | 24.5 kg |
Length : | 584 mm |
Stroke Length : | 51 mm |
Air Consumption : | 48 l/s |
Working Pressure : | 6 bar |
Penetration Rate : | 230 mm/min |
Weight : | 26 kg |
Shank Size : | 22 mm x 108 mm |
Optional Shank Size : | 25 mm x 108 mm |
Length : | 575 mm |
Air Consumption : | 48 l/s |
Air Inlet : | 20 mm |
Weight : | 26 kg |
Chuck Size : | 22 x 108 mm |
Length : | 668 mm |
Stroke Length : | 59 mm |
Air Consumption : | 58 l/s |
Penetration Rate : | 425 mm/min |
Weight : | 24 kg |
Chuck Size : | 22 x 108 mm |
Length : | 565 mm |
Stroke Length : | 59 mm |
Air Consumption : | 58 l/s |
Penetration Rate : | 425 mm/min |
